Ultimate Size Guide for CDs, DVDs, and Vinyl Records: Discs, Cases, Covers & Booklets
Ultimate Size Guide for CDs, DVDs, and Vinyl Records: Discs, Cases, Covers & Booklets
If you’re creating custom covers, printing artwork, or designing inserts for your music or movie collection, knowing the exact dimensions for CD, DVD, and vinyl cases is essential. Whether you need the size of a CD case cover, DVD case dimensions, or vinyl cover size, GD Print has everything you need. For over 40 years we have been helping customers from vinyl printing to CD booklet design, here’s your ultimate size reference for all your media needs.
Why Correct Dimensions Matter
Using the correct dimensions for CD covers, DVD inserts, and vinyl jackets ensures your artwork fits perfectly without trimming or stretching. This can improve appearance, add professionalism and avoid any issues you may have in the printing process. It also helps with the design process, by knowing your dimensions before you start, you understand the space you can work with and how best to create your work with the size in mind. Here are some other reasons why getting your sizing right is important:
• Professional look: Avoid pixelation or awkward white borders.
• Printing accuracy: Ensures your design is cut to size with proper bleed.
• Compatibility: Fits perfectly in standard CD cases, DVD cases, or vinyl sleeves.
• Ease of assembly: Incorrect dimensions can cause jams or require reprints, costing money.
• Preserve Media: Oversized or undersized cases can leave discs loose or too tight, risking scratches or warping.
• Compliance with Industry Standards: Incorrect sizing may prevent your product from being accepted in stores or libraries.
• Cost Efficiency: Getting it right saves time and money.
CD Sizes & Dimensions
Here are some common dimensions for CD, CD cases and more.
| Component | Standard Size |
| CD Disc Diameter | 120 mm (12 cm) |
| Mini CD Diameter | 80 mm (8 cm) |
| Jewel Case | 142 mm x 125 mm (10 mm spine) |
| Slim Jewel Case | 142 mm x 125 mm (5 mm spine) |
| CD Wallet/Sleeve | ~130 mm x 130 mm |
| Front Cover Insert | 120 mm x 120 mm |
| Back Tray Card | 151 mm x 118 mm |
| CD Booklet | 120 mm x 120 mm (4-12 pages) |
DVD Sizes & Dimensions
Here are some common dimensions for DVDs, DVD cases and more.
| Component | Standard Size |
| DVD Disc Diameter | 120 mm (same as CD) |
| Standard DVD Case | 190 mm x 135 mm (14 mm spine) |
| Slim DVD Case | 190 mm x 135 mm (7 mm spine) |
| DVD Cover Template | 273 mm x 183 mm (unfolded, includes spine) |
| DVD Insert/Booklet | 184 mm x 120 mm |
Vinyl Record Sizes & Dimensions
Here are some common dimensions for Vinyls, Vinyl cases and more.
| Component | Standard Size |
| 12-inch Vinyl Disc | 305 mm diameter |
| 10-inch Vinyl Disc | 254 mm diameter |
| 7-inch Vinyl Disc | 178 mm diameter |
| Vinyl LP Cover | 312 mm x 312 mm |
| Inner Sleeve | 308 mm x 308 mm |
| Gatefold Thickness | ~6 mm |
| Vinyl Booklet | ~305 mm x 305 mm |
Summary Table: All Media Sizes
Here are is a summary table for all the key sizes.
| Media Type | Disc Size | Case Size | Cover Size | Booklet Size |
| CD | 120 mm | 142 x 125 mm | 120 x 120 mm | 120 x 120 mm |
| DVD | 120 mm | 190 x 135 mm | 273 x 183 mm | 184 x 120 mm |
| Vinyl (12") | 305 mm | 312 x 312 mm | 312 x 312 mm | 305 x 305 mm |
Need Custom Printing for Your Media?
Your collection deserves more than plain, generic packaging. At GD Print, we specialise in high-quality, custom printing for all your media needs. Whether you’re looking to protect your collection or give it a personalised, professional look, we’ve got you covered. Here’s what we offer:
Vinyl Printing & Sleeves
• Custom vinyl jackets, inner sleeves, and vinyl cover printing designed to fit perfectly.
• High-quality finishes that protect your records and enhance your artwork.
CD & DVD Covers, Inserts & Booklets
• Professionally printed CD and DVD covers, custom booklets, and case inserts that make your media stand out.
• Perfect for musicians, film producers, and collectors who want a polished, retail-ready look.
Vinyl Stickers & Custom Decals
• Add a personal touch to your discs with custom vinyl stickers, labels, and decals.
• Great for branding, unique artwork, or creative packaging.
We make ordering easy with fast turnaround times, premium print quality, and a range of eco-friendly options. Whether you need CD cases, DVD covers, vinyl storage sleeves, or custom stickers, GD Print has the expertise to deliver.
[Order DVD Covers, CD Covers & Cases]
[Order Vinyl Jackets & Stickers]
FAQ: Common Questions About Media Dimensions
Q1: What are the dimensions of CD cover art?
The standard dimensions for CD cover art are 120mm x 120mm, designed to fit perfectly inside a jewel case without cropping.
Q2: What is the size of a CD case cover?
The typical CD case cover size matches the cover art at 120mm x 120mm, ensuring a snug fit in the case insert area.
Q3: What are the dimensions of a CD booklet?
A standard CD booklet usually measures 120mm x 120mm, the same as the cover size, though the page count can vary.
Q4: What is the standard DVD case size?
A standard DVD case measures 190mm x 135mm, while a full wrap for a cover design measures 273mm x 183mm (unfolded).
Q5: What about vinyl record cover sizes?
A 12-inch vinyl record cover typically measures 312mm x 312mm, providing full coverage for the LP while leaving space for protective sleeves.
Q6: Are there any custom options for CD and DVD covers?
Yes, you can create custom CD and DVD cover designs, including different dimensions of CD cover art, DVD cover templates, and special finishes through professional printing services like GD Print.
